Aluminium Curtain Wall Profile
- - Place of Origin: Foshan, China
- - Brand Name: GUANG YUAN
- - Model Number: GY001
- - Grade: 6000 Series
- - Alloy or Not: Is Alloy
- - Temper: T4-T6
- - Surface Treatment:
- - Mill Finish, Anodizing, Electrophoresis, Powder Coating, Polishing, Brush, Wood Grain, Fluorocarbon Coating, etc.
- - Deep Processing, Precise Cutting, Drilling, Bending, Punching, CNC and Aluminium Alloy Profile Fabrication
- - Quality Standard: China National Standard GB/T 5237-2008
- - Quality Certificate: ISO 9001:2015, ISO 14001:2015, CQM Certification, SGS
- - Application: Aluminium Curtain Wall Profile
- - Use purpose: Construction Buildings, villas and residential houses
PRODUCT Description
Guangyuan as a leading aluminum curtain wall manufacturer enterprise, with more than 28 years experiences in manufacturing high quality Aluminium Curtain Wall Profile. We have full range of curtain wall section, which can be categorized as: hidden framing glass curtain wall, exposed framing glass curtain wall, and semi-exposed framing glass curtain wall. We have 5000 ton extruding machine for manufacturing your large size Aluminium Curtain Wall Profile and have skillful labor to make sure the leading production time and the quality.
The reason choosing Guangyuan as aluminum curtain wall manufacturer are:
(1) Aluminium Curtain Wall Profile is good rigidity, light in weight and high in strength.
(2) Aluminium Curtain Wall Profile corrosion resistance, fluorocarbon paint up to 25 years without legs color.
(3) Aluminium Curtain Wall Profile technology is good. Using the first processing after the painting process, aluminum can be processed into a flat, curved and spherical and other complex geometric shapes.
(4) Aluminium Curtain Wall Profile is not easy to stain, easy to clean and maintain. The non adhesion of fluorine coating film makes it difficult to attach pollutants to the surface and has better cleaning property.
Contact Person: Mr. Adam Lin
Contact Info: +86-13630007855 (WeChat/Whatsapp)
Email:gyaluminium@hotmail.com
CLICK TO VIEW ALL PROFILES - SECTION 100&112
CLICK TO VIEW ALL PROFILES - SECTION 120
CLICK TO VIEW ALL PROFILES - SECTION 140&142&160&166
CLICK TO VIEW ALL PROFILES - SECTION 150&155&200
CLICK TO VIEW ALL PROFILES - SECTION 170&171&180
ITEM |
Aluminium Curtain Wall Profile |
||||||
Material |
6000 series aluminium alloy |
||||||
Temper |
T4, T5, T6 |
||||||
Profile Thickness | 0.5mm ~ 20mm | ||||||
Surface Treatment | Mill finish, anodizing, electrophoresis, powder coating, wooden color, fluorocarbon coating, polished, brushed, etc. | ||||||
Coating Film Thickness |
8~25um for anodizing film, 40~120um for powder coating film |
||||||
MOQ |
500kgs for each item |
||||||
Packing Details |
Inside: Packed with protection film to protect the surface of each profile |
||||||
Outside: Wrapped with hot shrink film and waterproof craft paper |
|||||||
Settlement Term |
Calculate by actual weight or theoretical weight in the drawing |
||||||
Delivery Time |
Die Tooling & Sample Testing: 7-15 days |
||||||
Mass Production Completed: 15~25 days after samples are confirmed by the buyer |
|||||||
FOB Port |
Guangzhou / Shenzhen / Foshan |
||||||
Payment Term |
T/T 30% for deposit and 70% for balance before shipping |
||||||
Production Capacity |
12,500 tons monthly and 150,000 tons annually |
||||||
Certificate and Standard |
CQM, ISO, SGS, BV |
||||||
Guarantee |
Surface finish can be stable for 10~20 years for indoor usages |
PACKING METHODS |
|||||||
1. Bundles Packing: | |||||||
Inside: packed with plastic protection film to protect the surface of each piece | |||||||
Outside: wrapped to be bundles by EPE foam and waterproof craft paper | |||||||
2. Carton Packing | |||||||
Inside: Each piece packed in one plastic polybag | |||||||
Outside: Numbers of pieces packed in one carton | |||||||
3. Wooden Pallet Packing | |||||||
Inside: Bundles or carton packing | |||||||
Outside: Numbers of bundles or cartons placed on one wooden pallet | |||||||
4. Customized packing requirement available | |||||||
SHIPMENT |
|||||||
Standard Loading Quantity | 1*20GP | 1*40HQ | |||||
Max. length: 5.85 meters | Max. length: 12 meters | ||||||
10-12 Tons | 22-26 Tons | ||||||
Standard Loading Port | HUANGPU / NANSHA / YANTIAN / SHEKOU | ||||||
Shipping Methods | Ocean shipment, air shipment, land transportation and multi-transportation, etc. |
