90 Aluminium Sliding Window

  • - Place of Origin: Foshan, China
  • - Brand Name: GUANG YUAN, DE YUAN NUO
  • - Frame Material: Aluminium alloy
  • - Open Style: Swing
  • - Mesh Material: Stainless steel and fiberglass
  • - Surface Treatment: Anodizing, electrophoresis, powder coating, wood grain, fluorocarbon coating
  • - Color: Silver, champagne, bronze, white, charcoal, black, brown, grey and wooden colors
  • - Quality Standard: AS2047
  • - Quality Certificate: ISO 9001:2015, ISO 14001:2015, CQM Certification, SGS
  • - Glass Standard: AS2208
  • - Glass Type: tempered glass, tinted glass, frosted glass, reflective glass, laminated glass and LOW-E glass

PRODUCT Description

Product Description

Carpet Crimping Profile

GUANGDONG GUANG YUAN ALUMINIUM CO., LTD. was established in 1993, which is located in Sanshui District, Foshan City, Guangdong Province, China. We are a professional aluminium extrusion company integrating the research and development, production and sales of aluminium profiles. We are mainly specialized in the production of architectural aluminium profiles, decorative aluminium profiles, heat sink aluminium profiles, industrial aluminium profiles and special aluminium profiles for aerospace and military industries, aluminium door and window system, and aluminium furniture, etc.

Aluminium sliding window is windows made of aluminum profiles with frame and window leaves structures, divided into ordinary aluminium sliding window and thermal break aluminium sliding window. Aluminium sliding window are beautiful, sealed, and high in strength. They are widely used in the field of construction engineering. In home improvement, aluminum alloy doors and windows are often used to package balconies.

Aluminium sliding window is the most commonly used in the construction of doors and windows in buildings. Now, for this type of sliding windows, they also have a lot of their own performance characteristics during use. Let's take a look at what aspects of this type of windows and doors have in the process of use.

First of all, for this aluminium sliding window, it has one aspect of characteristics during use, that is, it will not occupy our indoor space during use, unlike some casement windows, When it is opened, it is often affected by space problems, and its lighting effect is also very good. It can allow more indoor lighting. From the appearance, the overall shape is also very beautiful.

Also, for this type of interior door and window, it is also very flexible to switch during use, because when it is installed, it also uses high-grade slide rails. It only needs to be pushed gently when it is closed, it is very flexible, and the force it receives is also very uniform in use, which is not prone to some damage.

In addition, for this type of interior doors and windows, the range in which it can be installed is also very wide. It can be installed and used in some residential communities, it can also be used in some public building facilities, and it can also be used in many commercial places, etc., we can see it in a lot of different places.

Product Name

Aluminium sliding window

Manufacturing Standard

AS2047

Quality Certificate

ISO 9001:2015, ISO 14001:2015, CQM Certification, SGS

Aluminium Profiles

6063-T5 high quality thermal/non-thermal break aluminium profiles

Profiles Thickness

1.4mm for windows, 2.0mm for doors

Surface Treatment

Anodizing, electrophoresis, powder coating, fluorocarbon, and wooden color

Color

Silver, champagne, bronze, white, charcoal, black, brown, grey and wooden colors

Glazing Type

tempered glazing, tinted glazing, frosted glazing, reflective glazing, laminated glazing and LOW-E glazing

Glazing Thickness

Single tempered glazing: 5mm, 6mm, 8mm, 10mm and 12mm



Double tempered glazing: 4+12A+4mm, 5+9A+5mm, 5+12A+5mm, 5+15A+5mm, 5+19A+5mm and 6+12A+6mm

Mesh

Stainless steel security mesh, diamond mesh, aluminium security mesh, and fiberglass flyscreen



Retractable screen, fixed screen and sliding screen

Sealing

Chinese famous brand silicone and EPDM strips

Hardware

KINLONG, HOPPE, HOPO, SIEGENIA AUBI, CMECH

Architrave

Depending on the customer’s requirements

Guarantee

10 years to 20 years

Application

Residential houses, commercial buildings, luxurious villas, modular houses, prefab houses and steel structure houses

MOQ

1 set

Packing Details

EPE foam packing and wooden crate packing

Payment Term

1) T/T: 30% of total value as deposit by T/T within 3 days to confirm the order, and the balance to be paid by T/T before loading the container.



2) L/C: 30% of total value as deposit to be paid by T/T within 3 days to confirm the order, and the balance to be paid by L/C at sight after loading the container.



3) Big order: Pay 30% of total value as deposit by T/T within 3 day to confirm the order, and the balance to be paid by T/T after delivery against the copy of B/L.

STRUCTURAL PARAMETERS

Profile Thickness

Frame Depth

Sash Width

2.0mm

138mm

90mm

PERFORMANCE PARAMETERS

Heat Insulation(m2·K)

Sound Insulation(DB)

Water Tightness(PA)

Air Tightness

Wind Load(KPa)

4W

45DB

700PA

4.5≤92>3.0

3.5≤P3>4.0

Level 4

Level 4

Level 6

Level 8

Level 8

SHIPMENT

Standard Loading Quantity

1*20GP

1*40HQ



Max. length: 5.85 meters

Max. length: 12 meters



200 square meters

400 square meters

Standard Loading Port

HUANGPU / NANSHA / YANTIAN / SHEKOU

Shipping Methods

Ocean shipment, air shipment, land transportation and multi-transportation, etc.

FAQ

1. Are you a manufacturer or a trading company?

--- We are aluminium extrusion company specialized in the production of aluminium profiles and aluminium windows since 1993. And you are warmly welcomed to visit our factory.

2. What kinds of surface treatments can your company complete?

--- We can complete different kinds of surface treatments including mill finish, anodizing, electrophoresis, powder coating, wooden color, fluorocarbon coating, polishing and brushed, etc.

3. Can you produce customized windows?

--- Yes, we can produce the windows as per customers’ window specifications.

4. What is the lead time for mass production?

--- The time for mass production is around 20~45 days.

5. How can you ensure high quality?

--- We use primary aluminium raw materials to make aluminium billets by ourselves, never mixing scrap to lower the cost.

--- Our QC are strict with final product inspection and only accept qualified products.

--- All the products are produced according international standard.
