100/150 DEXIN SERIES SLIDING DOOR

  • - Place of Origin: Foshan, China
  • - Brand Name: GUANG YUAN, DE YUAN NUO
  • - Model Number: GY001
  • - Frame Material: Aluminium alloy
  • - Open Style: Swing
  • - Mesh Material: Stainless steel and fiberglass
  • - Surface Treatment: Anodizing, electrophoresis, powder coating, wood grain, fluorocarbon coating
  • - Color: Silver, champagne, bronze, white, charcoal, black, brown, grey and wooden colors
  • - Quality Standard: AS2047
  • - Quality Certificate: ISO 9001:2015, ISO 14001:2015, CQM Certification, SGS
  • - Glass Standard: AS2208
  • - Glass Type: tempered glass, tinted glass, frosted glass, reflective glass, laminated glass and LOW-E glass

PRODUCT Description

Product Description

Color/Patterm Option

#100/150 DEXIN SERIES SLIDING DOOR use Unique material combination, elegant color matching, smooth and bright line and surface combination, showing unlimited modern beauty, inspired by nature, and matching wood grain color, making aluminium sliding doors and windows more vibrant, with irresistible affinity, in line with humans The nature of being close to nature and the warm and elegant home style reflect the leisure, relaxed and pleasant lifestyle.

#100/150 DEXIN SERIES SLIDING DOOR adopts high-precision profile with a thickness of 1.4mm. aluminium sliding doors and windows is equipped with stainless steel rails as standard, copper rails are optional, and three-rails with diamond screens can be used as single wrap, double wrap, and no wrap.

The glass configuration for#100/150 DEXIN SERIES SLIDING DOOR is 4+12A+4 tempered hollow glass, which can be matched with craft glass such as lattice bars, dark flowers, decorative flowers, and ice flowers. The profile of commercial aluminium windows and doors design uses European standard hardware openings and connects multiple lock points to achieve a good anti-theft effect. aluminium sliding doors and windows leaf is equipped with an anti-shake device, which makes the sliding door light and no noise during the opening and closing process. commercial aluminium windows and doors  uses double-channel EPDM rubber strips, and uses the principle of pressure balance to achieve dry sealing.commercial aluminium windows and doors  is suitable for residential areas, villas, and balcony doors.

Product Name

100/150 DEXIN SERIES SLIDING DOOR

Manufacturing Standard

AS2047

Quality Certificate

ISO 9001:2015, ISO 14001:2015, CQM Certification, SGS

Aluminium Profiles

6063-T5 high quality thermal/non-thermal break aluminium profiles

Profiles Thickness

1.4mm for windows, 2.0mm for doors

Surface Treatment

Anodizing, electrophoresis, powder coating, fluorocarbon, and wooden color

Color

Silver, champagne, bronze, white, charcoal, black, brown, grey and wooden colors

Glazing Type

tempered glazing, tinted glazing, frosted glazing, reflective glazing, laminated glazing and LOW-E glazing

Glazing Thickness

Single tempered glazing: 5mm, 6mm, 8mm, 10mm and 12mm



Double tempered glazing: 4+12A+4mm, 5+9A+5mm, 5+12A+5mm, 5+15A+5mm, 5+19A+5mm and 6+12A+6mm

Mesh

Stainless steel security mesh, diamond mesh, aluminium security mesh, and fiberglass flyscreen



Retractable screen, fixed screen and sliding screen

Sealing

Chinese famous brand silicone and EPDM strips

Hardware

KINLONG, HOPPE, HOPO, SIEGENIA AUBI, CMECH

Architrave

Depending on the customer’s requirements

Guarantee

10 years to 20 years

Application

Residential houses, commercial buildings, luxurious villas, modular houses, prefab houses and steel structure houses

MOQ

1 set

Packing Details

EPE foam packing and wooden crate packing

Payment Term

1) T/T: 30% of total value as deposit by T/T within 3 days to confirm the order, and the balance to be paid by T/T before loading the container.



2) L/C: 30% of total value as deposit to be paid by T/T within 3 days to confirm the order, and the balance to be paid by L/C at sight after loading the container.



3) Big order: Pay 30% of total value as deposit by T/T within 3 day to confirm the order, and the balance to be paid by T/T after delivery against the copy of B/L.

STRUCTURAL PARAMETERS

Profile Thickness

Frame Depth

Sash Width

2.0mm

138mm

90mm

PERFORMANCE PARAMETERS

Heat Insulation(m2·K)

Sound Insulation(DB)

Water Tightness(PA)

Air Tightness

Wind Load(KPa)

4W

45DB

700PA

4.5≤92>3.0

3.5≤P3>4.0

Level 4

Level 4

Level 6

Level 8

Level 8

FAQ

1. Q: Where is your factory located?

A: Our factory is located in Foshan City, China, it takes about an hour from Guangzhou Baiyun Airport to our factory, about an hour from Canton Fair.

2. Q: What is your minimum order quantity?

A: Our minimum order quantity is 1 set.

3. Q: What are the colors available?

A: Our colors are available for our factory colors stock, and can be customized as per customer’s color sample.

4. Q: What is your lead time for production?

A: We can complete the order around 20-45 days.

5. Q: Did you export aluminum windows to overseas countries?

A: We have exported our profiles to South East Asia, Middle East, East Europe, South America and Africa, etc.
